Rosewood Archtop Bridge with Ebony Base and Metal Adjustable Thumbwheels

Description

This rosewood bridge will fit most archtop guitars and features and compensated wood saddle and chrome or gold thumbwheel and posts. The base of this bridge is extremely special as it’s design utilizing two feet with a hollow bottom rather than a solid mount base, creating a self-seating feature not found on other archtop bridges. This makes our AB-152 bridge a step above all the rest in ease of use and reliability.
Important Measurements –

Mounting Base length = 135.5mm
Mounting Base width = 15mm
height of base mount = 9.5mm
Height adjustment posts are 4mm width and threaded
Compensated Bridge Dimensions:
Approx E to E string spacing centered = 52mm
Height of Compensated bridge at center = 15.5mm at centre (measured without bridge base)
Centre to centre of the two mounting posts = 74mm
Total height with base and compensated bridge at center point = 25mm
