Manfrotto MVH500AH Fluid Head

Description

Fluid video head with flat base

• Built with a wider base for DSLR cameras with HD video function that moves to balance your camera
• Provides smooth shooting and fine control with up to 5kg of equipment
• Fluid cartridges on the pan and tilt axis to ensure that every camera movement is smooth, controlled and precise
• With a side-locking system that allows the camera and slide plate to quickly snap into the head from above, rather than having to be aligned and slid in from behind
• The head has a preset counterweight of 2.4 kg, but can support equipment of up to 5 kg
• With an Easy Link 3/8″ connector for attaching an external monitor or other accessory
• The flat base mount with a standard 3/8 ” thread makes the head versatile for different support combinations (tripod, slider, boom or crane)

Technical data:

• Top mount: 1/4″ screw / 3/8″ screw
• Base diameter: 60 mm
• Centre of gravity: 55 mm
• Front tilt: -70° / + 90°
• Panoramic rotation: 360°
• Working height: 10,5 cm
• Minimum working temperature: -20 °C
• Maximum working temperature: 60 °C
• Safety payload weight: 5 kg
• Pan Bar included
• Counterweight: 2.4 kg
• Material: Aluminium
• Weight: 0.9 kg
• Compatible accessories: 500HLV, 560BALLSH (not included)

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

• Available since August 2020

• Item number 498690

• Sales Unit 1 piece(s)

• Type Video Head

• max. Payload [kg] 5 kg

• max. Height [cm] 11 cm

• min. Height [cm] 11 cm

• Counterbalance Yes

• incl. 2-way Head Yes

• Fluid Control Yes

• incl. Ball Head No

• incl. Quick Release Plate Yes

• Adjustable Center Column No

• Plate Diameter [mm] 60 mm

• Spider No

• Colour Black

• Material Aluminium

• Weight [kg] 0,9 kg
