Description
The most dazzling and expansive collection of sounds ever put into a Korg synthesizer. NAUTILUS pushes the boundaries of what a performance synth and workstation is capable of. With the power of nine engines to drive a new approach to sounds, plentiful sampling, audio recording, effects, and processing power, there is simply no other synth that delivers more to explore sonically, with the workflow to get you there faster than ever. Korg spent years refining all our digital, analog, processing, and hardware technologies and delivering them in a way that helps the musician connect with their instrument. The result is the incredibly powerful, one-of-a-kind NAUTILUS.
Features:
Nine different sound engines offer massive expressive power
New sounds offered over three broad categories
The Dynamics knob makes delicate expression possible
Make intuitive changes to sounds with the Realtime knobs
A user interface designed for easy operation
Convenient arpeggiator and drum track functions
Color TouchView Display
Set list mode that demonstrates its power in live performances
Open Sampling System
16-Track MIDI Sequencer / 16-Track Audio Recorder
16 Onboard Effect Processors
USB/MIDI Host Ports Accommodate MIDI Control Surfaces
Smooth sound transitions that eliminate dropouts when changing sounds, regardless of the mode you’re in
Specifications:
System: NAUTILUS System Version 1.0
Keyboard: 88 key: RH3 (Real Weighted Hammer Action 3), A – C, Velocity sensitive is supported, after touch is not supported.
Synthesis Types: 9, SGX-2 – Premium Piano (Acoustic Piano), EP-1 – MDS Electric Piano (Electric Piano), HD-1 – High Definition Synthesizer (PCM), AL-1 – Analog Synthesizer (Analog Modeling), CX-3 – Tonewheel Organ (Tonewheel Organ Modeling), STR-1 – Plucked String (Physical Modeling), MOD-7 – Waveshaping VPM Synthesizer (VPM Synthesis), MS-20EX – Component Modeling Technology (Analog Modeling), PolysixEX – Component Modeling Technology (CMT Analog Modeling)
Maximum Polyphony: SGX-2 – 100 voices, EP-1 – 104 voices, HD-1 – 140 voices, AL-1 – 80 voices, CX-3 – 200 voices, STR-1 – 40 voices, MOD-7 – 52 voices, MS-20EX – 40 voices, PolysixEX – 180 voices
Preset PCM: RAM 496 MB / DISK 2.3G (ROM 1,771 Multi samples, 3,955 Drum samples)
Build-in Expansion PCM Libraries: EXs301 – German2 D Piano, EXs302 – Italian F Piano, EXs303 – Japanese Upright U Piano, EXs304 – Prepared Piano, EXs305 – Historical Keyboards, EXs306 – Vintage Keyboards 2, EXs307 – Strings & Synths, EXs308 – Guitar Collection, EXs309 – Bass Collection, EXs310 – World Essence, EXs311 – Background Loops, EXs312 – SFX & Hits, EXs313 – Found Percussions, EXs314 – Expansion Drums
PCM RAM Capacity: Approx. 2GB
Wave Sequences: 598 User memory, 377 Preload, Support for stereo multisamples, synchronization of individual notes, and tempo-based settings.
Tracks: 16-track MIDI sequencer + 16-track hard disk recorder + 1 master track.
Number of Songs: 200
Resolution: 1/480
テTempo: 40.00 – 300.00 (1/100 BPM resolution)
Maximum Memory: 400,000 MIDI events or 300,000 audio events
MIDI Tracks: 16 tracks plus the master track, 697 preset / 100 user patterns (per song), 18 preset/16 user template songs,
Audio Tracks: 16-track playback, 4-track simultaneous recording, WAV file format 16bit/24bit, Maximum Single-file Recording Time (mono): 80 minutes, Automation: Volume, Pan, EQ, and Send1/2, 10,000 regions (max.), Event Anchors, BPM Adjust
Other Functions: RPPR (Realtime Pattern Play and Record): 1 Pattern set per song
Disk Mode: Load, save, utility, data filer function (save/load MIDI System Exclusive data), CD-R/RW (UDF format read/write), ISO9660 Level 1.
Controllers: Joystick, Switches 1 & 2, Arpeggiator Control – On/Off, Latch, Gate, Velocity, Length, Swing, Tempo, Drum Track – On/Off, Swing, Drum SD, Tempo
Display: TouchView graphical user interface, 7 inch color TFT, WVGA (800 x 480 dots), adjustable brightness
Principal Specifications: Frequency Response – 20Hz-22kHz, +/-1.0dB, 10k Ω load, THD+N – 20Hz-22kHz, 0.01%, 10k Ω load (typical), S/N – 95dB (typical), Dynamic Range – 95dB (typical), Crosstalk – 95dB, at 1kHz (typical)
Outputs: L/Mono, R, Individual 1-4 – 1/4” TRS Balanced, Output Impedance: 350 Ω Stereo; 175 Ω Mono (L/MONO Only), Nominal Level – +4.0 dBu, Maximum Level – +16.0 dBu (when load impedance is 600 Ω or greater), Main Volume slider controls only Audio Output (Main) L/Mono and R, Headphones – 1/4” stereo phone jack, Output impedance – 33 Ω, Maximum Level – 60+60 mW (when load impedance is 33 Ω), Main Volume knob (link with Audio Output (Main)), USB-B – 24-bit, Sample Rate: 48 kHz, 2 channels, (Digital output of the same signals as Audio Output (Main) L/Mono and R)
Inputs: Audio Inputs 1 and 2 – 1/4” TRS Balanced, Input Impedance – 10 kΩ, Nominal Level – LINE +4 dBu, Maximum Level – LINE +16 dBu, Nominal Level – MIC –22 dBu, Maximum Level – MIC -10 dBu, Source Impedance – 600 Ω, USB-B – 24-bit, Sample Rate: 48 kHz, 2 channels
Control Inputs: Damper pedal (half damper supported), Assignable switch, Assignable pedal
MIDI: In, Out, Thru
USB: USB A (TYPE A) – For connection to external USB devices (QWERTY keyboards, MIDI controllers, ethernet adaptors, and storage), USB B (TYPE B) – MIDI/audio interface, MIDI: 1 (16 channel) input / 1 (16 channel) output, Audio: 2 channel input / 2 channel output, 2 USB high-speed ports (supports 480Mbps)
Disk Drives: 60 GB SSD (2.5”)
Power Supply: AC power supply terminal, Power switch
Dimensions: 1,437mm (56.57”) W x 387mm (15.24”) D x 139mm (5.47”) H
Weight: 23.1kg/50.93lbs.
Power Consumption: 40 W
Accessories: AC cord, Quick Start Guide
