Description
Ex-Display: Cosmetic Scratches on the bottom of the unit. See Pictures Attached.
The Alto Monitor EQ/Processor is designed to deliver precision equalization and notch filtering for monitor sound reinforcement systems. The Alto Monitor is perfect for modifying the frequency contour of audio signals, and is useful for a wide range of monitor-related audio reinforcement needs.
Features
15 band 2/3 Octave Equalizer
Two independent notch filters with selectable frequency
Low cut filter
Output LED level meter
Balanced XLR and unbalanced 1/4″ inputs and outputs
| Inputs | 1 x Balanced XLR 1 x Balanced 1/4″ TRS |
| Input Impedance | Balanced: 50 kOhm Unbalanced: 25kOhm |
| Operating Level | +4 dBu / 10 dBV |
| Maximum Input Level | Balanced and Unbalanced: +19 dBm |
| CMRR | > 55 dB @ 1 kHz |
| Outputs | 1 x Balanced XLR 1 x Balanced 1/4″ TRS |
| Output Impedance | Balanced: 60 Ohm Unbalanced: 30 Ohm |
| Maximum Output Level | +21 dBm |
| THD + N | 0.01% typ. 1 kHz, @ +4 dBu |
| Noise | > -92 dBr Unweighted 22 Hz to 22 kHz |
| Frequency Response | 10 Hz to 30 kHz, +/- 3 dB |
| Power Supply | USA/Canada 95 – 120V, 60 Hz |
| Power Consumption | 8W |
| Dimensions | 19 x 7.6 x 1.7″ (483 x 194.1 x 44mm) |
| Weight | 6.2 lbs (2.8 kg) |
